HP3-1000 Fits 2015 and up Pioneer 1000

Nothing Rocks Like a ProBox!

This ProBox top is extremely rigid and can tolerate repeated abuse. All ProBox tops can endure wind speeds of 100+ mph while being hauled to and from your favorite riding destination.

The ProBox top is constructed from multiple layers of 1/2", waterproof, ultralite fiberglass composite, then sealed with our ProBox Armor Coating. Each piece of the ultralite fiberglass composite is made up of two layers of woven fiberglass fabric and three layers of counter strand. The outer rim has three laminated pieces creating 15 layers for added strength and enabling it to withstand hard hitting blows that may come from overhead.

The design of our fiberglass composite top, with its engineered air space cavity and the 6 1/2" "injection woven" woofer with aluminum dome tweeter built-in 2-way crossovers ensures greater clarity.

Cleaning the roof system is no problem. Simply close all marine covers and power wash the complete roof system—speakers and all. Be safe, have fun and enjoy the best roof system on the market.

Note: Works with Honda windshield part # OSR72-HL4-100 (poly) and OSR71-HL4-A00 (hard-coat).

Specs/Equipment

The HP3-1000 is available in two package configurations. Click on a package to see details.

Features

  • JVC KD-X330BTS Media Player
  • (4) ProBox 6"x9" marine component speakers
  • Plastic marine cover
  • Quick release 3-pin power connector
  • (6) pre-drilled holes to locate and attach the bar tube clamps to roll bar (hardware included)
  • Dome light
  • (1) TSR36 front LED light bar (14,400 lumens)
  • (1) CSR-6 rear LED (2,400 lumens)
  • (2) Marine switches
  • One year warranty. Original receipt from date of purchase required for warranty work.

MSRP: $2,000

RGB components and color trim option not included.

Features

  • Wireless Bluetooth Media Control Center
  • (8) ProBox 6"x9" marine component speakers
  • (4) 4" ports
  • (1) ProBox 800W Plate Amp
  • Plastic marine cover
  • Quick release 3-pin power connector
  • (6) pre-drilled holes to locate and attach the bar tube clamps to roll bar (hardware included)
  • Dome light
  • (1) PRO-C20 LED light bar (16,000 lumens)
  • (2) PRO-C6 LEDs (4,800 lumens each)
  • (1) CSR-6 rear LED (2,400 lumens)
  • (3) Marine switches
  • One year warranty. Original receipt from date of purchase required for warranty work.

Tri-Light LED Beam Spread

Tri-light pattern

This photo shows an example of the beam spread of a tri-light LED configuration. Each LED bar features a double row of 5 watt Phillips LEDs. The flood part of the combo pattern delivers close range illumination, and the spotlight part delivers the extreme distance illumination. Click the image to enlarge.

MSRP: $3,600

RGB components and color trim option not included.

Highlights at a Glance

FM Radio Notice

High intensity LEDs may cause interference with FM radio. Packages with the Plate Amp option will not feature FM reception because of the Class D application.

Wireless Bluetooth® Media Control Center

The ProBox Media Control Center allows you to stream your tunes wirelessly via Bluetooth® technology from your mobile device to your ProBox top. The multifunction, single knob interface performs all the basic audio control functions, while the included USB charging port delivers power to your phone. A standard 3.5mm auxiliary port is included for wired connectivity, and two marine grade switches control the front and rear LED light bars.

Features

  • Bluetooth® control with volume, play/pause, next track, and previous track functions
  • 3.5mm AUX/USB (charge only) module
  • Front and rear light switches
  • Built-in fuse panel with (4) fused circuits — also serves as a power distribution block for better termination
  • Removeable front panel for easy access to fuses
Bluetooth logo

Bluetooth® Module Instructions

Click here to download a PDF (94 kB)

Bluetooth module instructions

ProBox 800W Plate Amp

Want to get loud? The new 800 watt (RMS) ProBox Plate Amp delivers. Its clean, flush design has no exposed wiring, keeping mud, water, dust and dirt from getting into the circuit board while off-roading. The back side of the Plate Amp has a closed cell gasket to ensure a good seal once the amp is mounted to the top. The Plate Amp is safe to power wash with no problems.

Features

  • Power @ 4Ω: 125 W x 4 channels (RMS)
  • Power @ 2Ω: 210 W x 4 channels (RMS)

ProBox 6x9 Marine Components

The ProBox 6x9 component speakers have been designed without a center pole behind the mid/tweeter. Instead, the mid/tweeter are suspended above the cone, making the 6x9 a true woofer with excellent bass response. This design also allowed us to mount the optional waterproof RGB LED circuit board behind the mid/tweeter. A reflective coating on the cone enhances the colors from the RGB LED circuit board, creating most impressive results.

Thanks to UV-resistant grilles, stainless steel hardware, plated speaker terminals, and rubber surrounds, the ProBox 6x9 component speakers are able to withstand the deteriorating effects of water, salt, and UV rays. Built-in 2-way crossovers ensure greater clarity.

  • Standard
  • Optional RGB

Features

  • Patented woven waterproof paper cone
  • Polypropylene woofer
  • Polypropylene mid-range
  • Aluminum tweeter
  • Automotive grade black painted finish
  • Power handling: 100 W (RMS)
  • Sensitivity: 94 dB
  • Frequency response: 55Hz - 20kHz
Smartphones

Control Your RGB LED Lights from Your Phone

With the EZ LED app, you can use your smartphone to simultaneously control the colors and flash pattern of the LEDs in your ProBox RGB tower speakers, RGB component speakers, and RGB wheel well kit. The EZ LED app is available for free from the iTunes App Store and Google Play.

EZ LED app icon
iTunes App Store Badge Google Play Badge

Assembled in the USA with parts from China. Availability, pricing, descriptions and specifications subject to change without notice.
